NI PXIE-5630
The NI PXIe-5630 module is a high-performance Vector Network Analyzer (VNA) manufacture
d by National Instruments (NI) and designed for radio frequency (RF) and microwave measurements. Based on PXI Express platform, it has the characteristics of modularity, flexibility and high performance, and is widely used in electronic design, production testing, scientific research and other fields.
Product description
Features:
Vector network analysis: Accurate measurement of the S-parameters of the network (transmission coefficient and reflection coefficient) used to characterize the characteristics of the network.
Frequency scanning: Fast frequency scanning in the broadband range to obtain the frequency response of the network.
Error correction: A variety of calibration methods are available to ensure the accuracy of measurement results.
Applications:
Electronic design verification: Verify the performance of circuit boards, antennas, filters, etc.
Production testing: Batch testing and screening of electronic products.
Scientific research: Used in wireless communication, radar, microwave devices and other fields of scientific research experiments.
Main parameters and specifications
Model: PXIe-5630
Brand: NI
Type: Vector network analyzer
Frequency range: 10 MHz ~ 6 GHz
Number of ports: 2
Dynamic range: 105 dB
Scanning speed: Fast
