NI PXIE-5105
The NI PXIE-5105 is a high-performance PXIe oscilloscope module from National Instruments (NI). It is designed for applications that require multi-channel, high sampling rates and synchronous measurements. The module is widely used in aerospace, automobile, communication and other fields.
Product name resolution
NI: Short for National Instruments.
PXIe, short for PXI Express, is a bus standard for modular instruments with high bandwidth and high-speed data transmission characteristics.
5105: NI Corporation designates the model number for this module to represent its specific performance and functionality.
Product description
The PXIe-5105 is an 8-channel, 12-bit resolution PXI oscilloscope. It has the following characteristics:
High sampling rate: up to 60 MS/s, capable of capturing rapidly changing signals.
Multi-channel synchronization: Eight channels are sampled simultaneously to ensure data consistency.
Flexible trigger: provides a variety of trigger modes to facilitate users to capture signals of interest.
Large capacity onboard memory: capable of storing large amounts of collected data.
Advanced software support: Equipped with software such as LabVIEW to facilitate user programming and data analysis.
