NI PXIE-5105
The NI PXI-5105 is a high-performance PXI oscilloscope module designed specifically for industrial applications. It offers a sampling rate of up to 12.5 GS/s and an analog bandwidth of 5 GHz to capture high-speed, high-precision signals. The module has the following features:
High performance: Provides up to 12.5 GS/s sampling rate and 5 GHz analog bandwidth to capture high-speed, high-precision signals.
Multi-channel: Support 4 analog channels, can measure multiple signals at the same time.
High accuracy: provides resolution up to 12 bits and can measure small signal changes.
Multiple trigger modes: Multiple trigger modes are supported to accurately capture events of interest.
Rich analysis functions: Provide rich analysis functions, such as waveform measurement, FFT analysis, phase analysis, etc., can help users analyze signals.
Product parameters:
Parameter value
Sampling rate 12.5 GS/s
Analog bandwidth 5 GHz
Number of channels 4
Resolution 12 bits
Record length 1024 MS
Trigger mode edge trigger, pulse trigger, video trigger, etc
Analysis function waveform measurement, FFT analysis, phase analysis, etc
Operating temperature -20°C to 70°C
Storage temperature -40°C to 85°C
