MOOG D136-001-007
Moog D136-001-007 is a controller driver module for controlling Moog servo motors. It adopts advanced power electronics technology and microcontroller technology, which can provide high precision and high reliability control for servo motor. The module has the following features:
High precision: Advanced current sensing and control technology can provide high precision c
urrent control and position control.
High reliability: With industrial grade components and design, it can work in harsh environments and has a wide operating temperature range.
Easy to use: With a user-friendly interface and multiple configuration options, it is easy to use and maintain.
Complete functions: In addition to the basic motor control functions, it also provides overload protection, undervoltage protection, overheat protection, diagnostic functions and other functions.
Product parameters:
Parameter value unit
Rated voltage 24 VDC V
Rated current 7 A A
Continuous power 168 W W
Peak power 336 W W
Speed range 0 to 3000 rpm rpm
Torque range from 0 to 1.7 Nm
Operating temperature range -40 to +85 °C
Relative humidity 5% to 95% % (non-condensing)
