METSO PDP403
The METSO PDP403 module is an isolated I/O terminal for isolating, converting and transmitting field instrument signals to the control system. The module has the following features:
High precision: The measurement accuracy is 0.1%FS
Wide range: A variety of ranges can be selected to meet different application requirements
High reliability: Modular design, strong anti-inte
rference ability, stable and reliable
Easy to use: easy to install and configure
Product parameters:
Power supply voltage: 24V DC
Power consumption: < 5W
Input signal: current, voltage, RTD, thermocouple, etc
Output signal: 4-20mA DC, HART
Isolation voltage: 2500V RMS
Protection level: IP67
Specifications:
Dimensions: 110mm x 60mm x 30mm
Weight: 200g
Material: Aluminum alloy
Operating temperature: -40℃ to 70℃
Humidity: 0% to 95% RH (non-condensing)
Application field:
METSO PDP403 modules are widely used in oil, gas, chemical, power, metallurgy, water treatment and other industries, and can be used for the isolation, conversion and transmission of field instrument signals.
Product features:
High precision and reliability
Wide range, multiple output signals
