IBA ibaFOB-4i-S
IBA The Chinese name of the ibaFOB-4i-S module is the ibaFOB-4i-S Optical Fiber Data Acquisition Module. It is a fiber optic data acquisition module produced by IBA for the acquisition of analog and digital signals. It has the following characteristics:
High performance: It can collect analog and digital signals with high precision and high sampling rate
High reliability: Optical fiber transmission mode, strong anti-interference ability, to ensure the stability and reliability of data transmission
Easy to use: Provide a variety of parameter Settings and debugging functions, easy to operate
Strong versatility: supports a variety of sensors and field devices
Product description
IBA The ibaFOB-4i-S module uses fiber optic transmission to transmit analog and digital signals from field equipment to the control room or data acquisition system. It has the following main functions:
Analog voltage and current signals are collected
Acquisition of digital signals
Support HART protocol
Provides the time synchronization function
Product parameter
Parameter value
Number of channels 4
Analog input range ±10 V
Analog resolution 16 bit
Analog sampling rate up to 10 kHz
Digital input 8 channels
Digital quantity resolution 24 bit
Digital sampling rate up to 1 MHz
Communication interface fiber
Power supply voltage 24 VDC
Power consumption ≤ 20 W
Operating temperature range -20°C to +70°C
Storage temperature range -40°C to +85°C
Relative humidity 5% to 95% (non-condensing)
Vibration resistance 2 g (10 Hz to 500 Hz)
