GE THED136100WL
The GE THED136100WL module is a high-performance digital output module for the VersaxMax I/O platform from General Electric Company (GE) for controlling various switchgear. The module has the following features:
16 independent digital output channels: Each channel can provide 2A current output
High switching speed: up to 10 kHz per channel
High reliability: Solid state relay design ensures long-term reliable operation
Multiple protection functions: overload protection, short circuit protection, thermal protection, etc
LED indicator: Indicates the output status of each channel
Support a variety of connection methods: support screw terminal connection and DIN rail connection
Product parameter
Parameter value
Number of output channels 16
Output Type Numeric output
Output current 2A per channel
Switching speed 10 kHz per channel
Power supply voltage 24 VDC
Power consumption 8 W
Dimensions 90 mm x 30 mm x 25 mm
Weight 70 g
