GE IC695CHS016
The GE IC695CHS016 module is a Series 90-30 PLC universal backplane produced by General Electric Company (GE) to expand the number of I/O modules in the PACSystems RX7i programmable logic controller (PLC). The module has the following features:
16 slots: can accommodate a variety of Series 90-30 I/O modules
Supports a variety of I/O types, including analog I/O, digital I/O, and serial I/O
High backplane capacity: Up to 256 I/O points are available
Hot swap: Supports hot swap of I/O modules for easy maintenance
Easy to use: Supports automatic configuration and diagnostics
Product parameter
Parameter value
Number of slots 16
Supports analog I/O, digital I/O, and serial port I/O
The maximum capacity of I/O points is 256
Backplane power supply 24 VDC
Power consumption 20 W
Dimensions 233 mm x 178 mm x 45 mm
Weight 1.5kg
