GE IC695CHS012
The GE IC695CHS012 is a 12-slot universal backplane of the PACSystem RX3i series. This backplane supports PCI (IC695) and serial (IC694) -based I/O with optional modules for a dual bus backplane. It is an essential component of the control system and provides the housing for the RX3i modules and connections. In addition, it carries the communication bus12 for internal communication between modules.
The backplane enables modules to be hot-swappable or removable and plugged in when powered on, which effectively reduces downtime and allows maintenance activities such as module replacement and integrity verification without affecting the current operating mode of the attached controller and module 2.
Product parameters:
The power consumption is 600 mA at 3.3 V DC and 240 mA at 5 V DC.
The physical dimensions are 18.01 x 5.57 x 5.80 (457.5 x 141.5 x 147.32) 2.
Supports horizontal mounting and can be installed in a housing with IP20 / NEMA/UL Class 1 protection class2.
Specifications:
Each slot in the backplane can be configured to receive different components, such as DC power and AC power 2.
The terminals in slots 7 and 8 are typically used to isolate external power supplies 2.
Supports horizontal placement and requires at least 102 mm (4 inches) of space on all four sides for normal operation and air cooling 2.
Supported input terminals use a single wire of 14 to 22 AWG 2.
