GE IC694MDL754
The GE IC694MDL754 is a digital volume output module manufactured by GE Fanuc (now Emerson Automation Solutions) in the RX3i family. This module is mainly used to control external devices or indicate system status, such as control relays, indicators, etc. It can send digital signals to external devices according to PLC instructions to realize the switch control of equipment.
Main function
Digital output: Provides 32 independent digital output points, each of which can be controlled individually.
Electronic Short Circuit Protection (ESCP): With electronic short circuit protection function, can effectively protect the module and the connected load.
Positive logic: Positive logic is used, that is, a high level indicates that the output is valid.
Flexible configuration: It can be flexibly configured through programming software to set parameters such as output type and response time.
Product parameters and specifications (please refer to the official documents for specific parameters)
Model: IC694MDL754
Type: Digital output module
Output points: 32 points
Output voltage: 12/24 VDC
Logical type: positive logic
Protection function: electronic short circuit protection
Mounting method: DIN rail mounting
Application field
Industrial automation: used to control various industrial equipment, such as machine tools, robots, packaging machines, etc.
Process control: used to control actuators such as valves and motors.
