GE IC694MDL645
The GE Fanuc IC694MDL645 module is a 16-point, 24-volt DC, plus/minus logic input module belonging to the GE Fanuc RX3i series. The module provides a set of 16 input points and has a shared power input terminal. It supports discrete inputs and has no backplane restrictions. The input module can be configured with positive or negative logic. There are 16 LED indicators on the module to indicate the on/off status of each point. The module is compatible with a variety of input and field devices such as switches, buttons and BCD thumb wheels. The IC694MDL645 establishes an interface between these devices and the PLC.
Product parameters:
Rated voltage: 24 VDC
Input voltage range: 10.5 to 30 VDC
Input points per module: 16 (1 group)
Current at each input point: 7 mA
On-state voltage: 21 VDC
Off state voltage: 0.5 VDC
Maximum input frequency: 5 kHz
Surge current: 3 A per channel
Surge duration: 10 ms
Power consumption per input point: 22.4 mW
Module power consumption: 4.5W
Operating temperature range: -20 to +60 °C
Storage temperature range: -40 to +85 °C
Mounting method: DIN rail mounting
Weight: About 120 g
