GE IC694ALG223The GE IC694ALG223 is a high density simulation input module for the RX3i programmable Automation Technology Control Board (PAC) manufactured by GE Fanuc (now part of VeTI Automation Technologies). The module is designed with sixteen single-ended input channels that can be individually configured to accept 0-20 mA, 4-20 mA (standard), and 4-20 mA (enhanced) input data signals, and each channel can be used independently. The module is mainly used to connect measurement and data signal devices, such as smart transmitters, sensors, signal isolators, etc., to convert the received analog data into a digital equivalent by an embedded digital-to-analog converter (ADC) 1 for integration.
Product parameters:
Input channels: 16 single-ended input channels 1
Input signal range: 0-20 mA, 4-20 mA (standard), 4-20 mA (enhanced) 1
Screen resolution: 12 bits 1
Conversion rate: 13 ms (some information mentions a refresh rate of 6 ms, which may refer to different measurements or scenarios) 1
Factory calibration: 4µA per count in the range of 4 to 20 mA; When raised from 0 to 20 mA and 4 to 20 mA, each count is 5µA1
Current consumption: Internal current consumption is 120 mA (5VDC total phase voltage) and 65 mA (independent current for each current loop, powered by an external 24 VDC supply) 1
Operating environment temperature: not directly mentioned, but generally industrial automation equipment has a wide temperature range, which may cover -40 ° C to 70 ° C or similar range 2
Specifications:
Physical dimensions: Specific dimensions are not provided directly, but are usually designed to fit the PACSystems RX3i main box1 based on installation requirements
Interface compatibility: Can be used for local or distributed system I/O modules on Rx3i and RX7i control board platforms
Power requirements: Internal power requirements are 5VDC and 24VDC1
