GE IC693ALG223
The GE IC693ALG223 module is an analog input module for the Series 90-30 Programmable Logic controller (PLC) series produced by GE. The module has the following features:
16 analog input channels
Support current input: 4-20 mA
High precision measurement
Programmable filter
The GE IC693ALG223 module can be used to connect various current sensors to acquire analog signals. The module can be used for the following applications:
Factory automation: Monitoring the status of machines and equipment, such as temperature, pressure, flow, etc
Process control: control process parameters, such as temperature, pressure, flow, liquid level, etc
Building automation: Control HVAC system, lighting system, etc
Power system: Monitoring the status of the power system, such as current, voltage, power, etc
Product parameter
Parameter value
Number of channels 16
Input Type Analog input (current)
Input range 4-20 mA
Accuracy 0.1%
Resolution 16 bit
Update rate 2.5 ms
Power supply voltage 24 VDC
Power consumption 1.2W/channel
Dimensions 95 mm x 45 mm x 25 mm
Weight 130 g
