GE IC670MDL640
The GE Fanuc IC670MDL640 module is an 8-point, 24-volt DC, plus/minus logic input module for the 90-30 series programmable logic controllers (PLCS). The module provides a set of 8 input points and has a shared power input terminal. It supports discrete inputs and has no backplane restrictions. The input module can be configured with positive or negative logic. There are 8 LED indicators on the module to indicate the on/off status of each point. The module is compatible with a variety of input and field devices such as switches, buttons and BCD thumb wheels. The IC670MDL640 establishes an interface between these devices and the PLC.
Product parameters:
Rated voltage: 24 VDC
Input voltage range: 10.5 to 30 VDC
Input points per module: 8 (1 group)
Current at each input point: 7 mA
On-state voltage: 21 VDC
Off state voltage: 0.5 VDC
Maximum input frequency: 5 kHz
Surge current: 3 A per channel
Surge duration: 10 ms
Power consumption per input point: 22.4 mW
Module power consumption: 2.5W
Operating temperature range: -20 to +60 °C
