GE IC200ALG630
The GE IC200ALG630 is a VersaMax analog input/output module manufactured by General Electric (GE) and now manufactured by Emerson Automechanic1. The module has advanced diagnostic capabilities and can receive input signals from multiple analog devices and convert them into 16-bit parsed digital data. At the same time, it can also output analog voltage or current signals to controllable devices. The IC200ALG630 is particularly suitable for non-standard millivolt signals provided by temperature measurement requirements or integrated sensors, and supports type J, K, T, S and R thermocouples 1. In addition, the module has short circuit protection and overvoltage protection to ensure the safety of the module, and has input/output isolation to ensure the safety and reliability of the data 2.
Product parameters:
Analog input channels: 8 channels
Analog input range: ±10 VDC, 4-20 mA
Analog input resolution: 16 bits
Analog input accuracy: ±0.3%FS
Analog input conversion time: 0.4ms
Number of analog output channels: 8
Analog output type: Voltage/current
Analog output range: 0-10 V, 4-20 mA
Analog output resolution: 16 bits
Analog output accuracy: ±0.3%FS
