The GE DS3800NTCF module is a high-performance digital output module for the Mark VI series programmable controllers (PCS) produced by General Electric Company (GE) for controlling various switchgear. The module has the following features:
32 independent digital output channels: Each channel can provide 2A current output
High switching speed: up to 10 kHz per channel
High reliability: Solid state relay design ensures long-term reliable operation
Multiple protection functions: overload protection, short circuit protection, thermal prote
ction, etc
LED indicator: Indicates the output status of each channel
Support a variety of connection methods: support screw terminal connection and DIN rail connection
Product parameter
Parameter value
Number of output channels 32
Output Type Numeric output
Output current 2A per channel
Switching speed 10 kHz per channel
Power supply voltage 24 VDC
Power consumption 16 W
Dimensions 230 mm x 130 mm x 40 mm
Weight 1.5kg
