GE DS3800HPIB
The GE DS3800HPIB module is a General Electric Company (GE) HP-IB interface module for the PACSystems RX7i Programmable Logic Controller (PLC). The module has the following features:
Meets IEEE 488.2 standard
Supports multiple data transfer rates up to 1 Mbps
Multiple devices can be connected
Provides a variety of programming functions
The GE DS3800HPIB module can be used to connect various HP-IB instruments and devices to enable PLC communication with external devices. The module can be used for the following applications:
Instrument control: control a variety of instruments and equipment, such as oscilloscopes, spectrometers, data collectors, etc
Data acquisition: Collection of data from instruments and equipment for analysis and processing
Automated testing: Perform automated testing and measurement
Product parameter
Parameter value
Interface type HP-IB
The maximum data transfer rate is 1 Mbps
Number of devices Multiple devices can be connected
Power supply voltage 24 VDC
Power consumption 2 W
Dimensions 95 mm x 45 mm x 25 mm
