GE 469-P1-HI-A20-E
The GE 469-P1-HI-A20-E Redundant Motor Protection relay module is part of the Multilin 469 family of products introduced by General Electric (GE) to provide reliable protection for motors. The module has the following features:
High reliability: With redundant design, even if one channel fails, the other channel can work normally, ensuring the safe operation of the motor.
Versatility: Supports a variety of protection functions, such as overload, short circuit, overvoltage, undervoltage, ground fault, etc.
Easy to use: A friendly configuration interface makes it easy to set and manage protection
parameters.
Scalability: Supports a variety of communication interfaces and can be easily integrated into existing control systems.
Product parameters:
Power supply voltage: 24V DC or 48V DC
Power consumption: < 20W
Input signal: current, voltage
Output signal: relay contact, RS-232/RS-485 communication
Protection level: IP67
Specifications:
Dimensions: 233mm x 167mm x 30mm
Weight: 500g
Material: Aluminum alloy
Operating temperature: -40℃ to 70℃
Humidity: 5% to 95% RH (non-condensing)
