FOXBORO P0926HW
The FOXBORO P0926HW module is a high-speed counting module for the Foxboro Evo family
of programmable controllers (PLCS). It provides a convenient way to accurately measure and control high-speed pulse signals. The module has the following features:
Supports multiple types of pulse signals
High precision and reliability
Easy to install and maintain
Rugged for use in harsh environments
Meets IEC 60529 IP67 protection rating
Product parameter
Parameter value
Module Type High-speed counting module
Applicable to PLC Foxboro Evo series
Supported pulse signal types square wave, sine wave, triangle wave, etc
The maximum counting frequency is 10MHz
The counting accuracy is 0.1ns
Resolution 32 bit
Response time <1μs
Noise <0.1%FS
Common mode rejection ratio >60dB
Operating temperature range -40°C to 70°C
Relative humidity 5% to 95% (non-condensing)
Vibration 5g peak, 5Hz to 350Hz
