EPRO PR6424/000-131+CON031
The EPRO PR6424/000-131+CON031 is a measurement system with an integrated eddy current sensor and signal converter. It is mainly used to measure the radial and axial dynamic displacement, position, eccentricity and speed/keyway of large rotating shafts. The product is commonly used in critical rotating machinery that requires high precision measurement and reliability, such as steam turbines, gas turbines, water turbines, compressors, pumps and fans.
Main function
Non-contact measurement: The use of eddy current principle to achieve non-contact measurement of the rotating shaft.
Multi-parameter measurement: Measurement of radial and axial displacement, position, eccentricity, and speed/keyway.
High precision: With high measurement accuracy, can meet the demanding measurement requirements.
Wide measuring range: with a wide measuring range, suitable for different sizes of rotating shafts.
High temperature resistance: can work stably in high temperature environment.
Signal conversion: Built-in signal converter converts sensor signals into standard electrical signals.
Product parameters (part)
Parameter value unit
Measuring range -2.0 mm to 2.0 mm mm
Accuracy ±0.079 mm
Repeatability ±0.039 mm
