BENTLY 3500/53
The BENTLY 3500/53 module is a highly reliable and responsive tachometer system designed specifically for overspeed protection of machinery. It can receive the signal of eddy current sensor or magnetic sensor, and process the signal, so as to realize the real-time monitoring and overspeed warning of mechanical equipment. In addition, the module meets the American Petroleum Institute’s standards for overspeed protection, guaranteeing its safety and reliability in industrial applications. At the same time, the 3500/53 module can be used in conjunction with other 3500series modules to form a multi-channel inspection system, improving the flexibility and accuracy of the system.
Product parameters:
Input signal: Receive eddy current sensor or magnetic sensor signal, input signal range is +10.0V to -24.0V12.
Input impedance: 20kΩ12.
Power consumption: Normally 8.0W12.
Sensor type: Supports a variety of sensors such as the Bently Nevada 3300 8mm vortex sensor, 3300 16mm High temperature vortex sensor (HTPS) 12.
Output: Includes LED indication and recorder output, LED indicates the working status of the module, recorder output is +4 to +20mA, the output value is proportional to the full scale range of the module 1.
Product Specifications:
Operating voltage: 24Vdc, maximum current is 40mA3.
Communication interface: Support RS-485 communication protocol, communication rate of 9600bps3.
Measuring range: Depending on the type of sensor connected, it is usually possible to measure a wide range of speed or vibration data 3.
