BENTLY 3500/50-01-01-00-00
BENTLY 3500/50-01-01-00-00 module
Product name
The BENTLY 3500/50-01-01-00-00 module is also known as:
3500/50 Tachometer Module
3500/50 speed meter module
Bently Nevada 3500/50-01-01-00-00 rate-meter module
Product description
The BENTLY 3500/50-01-01-00-00 module is a rate-meter module manufactured by Bently Nevada that measures and monitors the speed, acceleration, and direction of rotating machinery. The module can accept input signals from proximity probes or magnetic pickups and convert them into electrical signals for processing.
The 3500/50-01-01-00-00 module has the following features:
Single-channel design allows you to measure the speed, acceleration and direction of a channel
High precision, measuring accuracy up to 0.1%
Wide range, measuring from 0.1 rpm to 30,000 rpm
Fast response time for frequencies up to 10 kHz
Peak hold function to record the highest RPM, highest reverse speed or number of reversals
Multiple output modes, including analog output, digital output and relay output
Product parameter
Parameter value unit
Number of channels 1
Input type close to probe or magnetic pickup –
Measuring range 0.1 rpm to 30,000 rpm
Accuracy 0.1% –
Response time ≤ 10 μs μs
Output mode analog output, digital output, relay output –
The supply voltage is 24 VDC V
Power consumption ≤ 5 W W
Operating temperature -40°C to +85°C °C
Protection class IP67 –
drive_spreadsheet
Export to Google Forms
specification
Dimensional value unit
Length 165 mm mm
Width 85 mm mm
Height 30 mm mm
Weight 0.5 kg kg
