BENTLY 3500/45-01-00
Product Description:
The BENTLY 3500/45-01-00 is a four-channel position monitoring module designed to measure and monitor the axial or radial position of rotating machinery. It can accept input from various types of sensors, including:
Proximity probe
Linear Variable Differential Transformer (LVDT)
Rotating potentiometer
The BENTLY 3500/45-01-00 module can be used for a variety of applications, including:
Bearing wear monitoring
Valve positioning monitoring
Gear mesh monitoring
Other rotating machinery position monitoring
Product parameters:
Number of channels: 4
Input range:
Approach probe: ±10 V peak
LVDT: ±5 V peak
Rotary potentiometer: 0% to 100%
Measurement accuracy: ±0.1%
Resolution: 0.01%
Frequency range: 0.1 Hz to 10 kHz
Output: 4 relay outputs, programmable for alarm or fault indication
Communication: RS-485 communication interface
Specifications:
Dimensions: 254 mm x 152 mm x 44 mm
Weight: 2.3kg
Power supply: 24 V DC
Operating temperature: -40°C to +85°C
Storage temperature: -55°C to +90°C
Protection level: IP67
Main features:
High precision and resolution
Wide measuring range
Multiple input types
Multiple output options
RS-485 communication interface
