BENTLY 3500/25
The BENTLY 3500/25 Keyphasor module is a half-height, 2-channel module designed to provide key phase signals to monitor modules in the 3500 frame. The main function of this module is to receive input signals from eddy current sensors or electromagnetic sensors and convert these signals into digital key phase signals. A digital key phase signal can indicate when to rotate the key phase marker on the shaft through the key phase probe. This module enhances key signal processing and is fully compatible with existing Keyphasor modules for use with legacy systems 123.
Product parameters:
Physical parameters: The dimensions (H x W x D) of the main module are 119.9mm x 24.4mm x 256.5mm (4.72in x 0.96in x 10.10in) and the weight is 0.34kg (0.76lbs) 4.
Input/Output: This module receives the signal from the proximity probe or magnetic pickup and converts it into a digital signal 23.
Signal processing: The module is capable of processing multiple key phase signals and has a strong signal processing capability 3.
Product Specifications:
Number of channels: Half-height dual-channel module, each module has 2 input channels 12.
System configuration: The 3500 mechanical protection system can be installed with up to 2 key phase modules to receive 4 key phase signals. In specific configurations, the system can accept up to 8 key phase signals 123.
Signal conversion: Converts the input signal from the sensor into a digital key phase signal 123.
