BENTLY 3500/25-01-03-00
The BENTLY 3500/25-01-03-00 is an enhanced Keyphasor module for converting signals from sensors, such as magnetic pickups or proximity probes, into digital Keyphasor signals. Keyphasor signals are used to measure shaft speed and phase and are an essential part of the BENTLY 3500 series monitoring system.
Product parameters:
Number of channels: 2
Input range: ±10 V peak
Input frequency: 0.1Hz to 10kHz
Output: Keyphasor signal, event signal, fault indication signal
Communication: RS-485 communication interface
Specifications:
Dimensions: 119 mm x 48 mm x 25 mm
Weight: 0.4kg
Operating temperature: -40°C to +85°C
Storage temperature: -55°C to +90°C
Protection level: IP67
Main features:
High precision and resolution
Wide input range and frequency range
Multiple output options
RS-485 communication interface
Rugged design
Suitable for various industrial applications
Application Case:
Measure shaft speed and phase
Carry out vibration analysis
