BENTLY 3300/55-03-01-15-15-00-00-01-00
BENTLY 3300/55-03-01-15-15-00-00-01-00 module also known as:
Dual probe probe monitor module
3300/55 Dual Proximity Probe Monitor Module
Bently Nevada 3300/55-03-01-15-15-00-00-01-00 Dual probe probe monitor module
Product description
The BENTLY 3300/55-03-01-15-15-00-00-01-00 module is a dual probe probe monitor module m
anufactured by Bently Nevada for the monitoring of displacement, vibration, and other parameters of rotating machinery. The module has the following features:
2 probe input channels to connect two dual probe probes
Multiple probe types are supported, including radial probe, axial probe, and gap probe
Wide range, displacement measurement range is 0.001 mm to 10 mm, vibration measurement range is 0.001 g to 10 g
High precision, displacement measurement accuracy up to 0.01mm, vibration measurement accuracy up to 0.05g
Fast response time, response time is less than 10 ms
Multiple output modes, including analog output, digital output and relay output
Product parameter
Parameter value unit
Number of channels 2
Probe type Radial probe, Axial probe, Gap probe –
Displacement measurement ranges from 0.001 mm to 10 mm
Vibration measurement range 0.001 g to 10 g g
Displacement measurement accuracy is 0.01 mm mm
Vibration measurement accuracy 0.05 g g
Response time < 10 ms ms
Output mode analog output, digital output, relay output –
The supply voltage is 24 VDC V
Power consumption ≤ 5 W W
Operating temperature -40°C to +85°C °C
Protection class IP67 –
drive_spreadsheet
specification
Dimensional value unit
Length 165 mm mm
Width 85 mm mm
Height 30 mm mm
