The ABB UDC920BE module is a controller designed for industrial applications with a range of advanced control and monitoring functions. The module is easy to install, easy to debug and easy to maintain, and supports the development of the global drive field of the L200 series inverter 1.
The UDC920BE module is rich in functions, including enhanced PID function, fan ON/OFF function to extend fan life and reduce inverter body energy consumption, zero-pitch installation, intelligent output terminal can delay action and logical calculation function, analog setting calculation function, analog input selection and analog input break detection function, three-wire hold function, etc. 1. In addition, it also supports the RS-485 communication interface standard built-in (MODbus-RTU) 1, provides NEMA4X options, has advanced construction and easy wiring and maintenance features 1.
Product parameters:
Dimensions: 150mm × 100mm × 50mm2.
Weight: 500g2.
Operating temperature: -40℃~ +85℃2.
Power Supply: 24V DC2.
Input mode: analog, digital, serial 2.
Output: Analog, digital, Relay 2.
Specifications:
Control functions: including PID control, cascade control, feedforward control, etc. 2.
Monitoring function: Support temperature, pressure, flow and other monitoring 2.
Communication interface: Support RS-232, RS-485, Modbus, Profibus, etc.
Certification: including CE, UL, cUL, RoHS, etc.
