ABB PFEA111-20
Functions and applications: PFEA111-20 module is a high-performance industrial display module or tension controller, with high resolution and clarity display, used to display a variety of data and information, real-time process data, alarm information, system status, etc. 12. It helps operators monitor and control systems in real time. In addition, the module is also suitable for industrial automation applications that require tension control2.
Display features: Support digital display, graphic display, curve display and other display modes, users can choose the appropriate display mode according to specific needs.
Interactivity: Often with touch screen features, allowing users to interact with the display to operate, select, and control display content in a more intuitive and flexible manner.
Other features: In some descriptions, the module has bandwidth options (e.g. 60MHz, 100MHz, 200MHz), sampling rates up to 2GS/s, as well as rich capture methods and multiple user interface options, such as Chinese support, etc. 2.
Product parameters:
Bandwidth: Provide 60MHz, 100MHz, 200MHz and other bandwidth options.
Sampling rate: up to 2GS/s, support 2 or 4 channels 2.
Capture methods: including peak detection, sampling, average, single capture methods 2.
Display: Color or monochrome LCD display with 1/4 “VGA passive resolution 2.
Input voltage: 300VRMS CAT ‖; Decrement to 20dB/+ base 2 above 100KHz to 13vp-AC.
Specifications:
Axial load: up to 15N3.
Temperature rise: In the Max state, the temperature rise should be kept below 80K 3.
Operating temperature: The operating temperature range is between 0℃ and +50℃ 3.
Insulation class and resistance: The insulation class is B(130℃), and the insulation resistance is 100MΩMIN@500V DC3.
Step accuracy and number of phases: the step accuracy is 5% and the number of phases is 23.
