ABB LDGRB-01
Functions and Applications:
Ground fault monitoring: The ABB LDGRB-01 is a compact, DIN rail mountable device designed to provide reliable ground protection for ungrounded AC and DC systems.1 It is primarily used to monitor leakage current through fault flow to ground and to trip circuit breakers when a fault is detected, thereby protecting equipment and personnel from electrical hazards1.
Applications: The equipment is widely used in industrial automation, power systems, buildings and other places requiring ground protection12.
Product parameters:
Motor power range: 0.12~ 200 kW3.
Torque range: 85~ 18000 nm 3.
Ratio range: 5~ 280003.
Input speed range: 750~ 3000 rpm3.
Output speed range: 0.05~ 500 rpm3.
Product Specifications:
Input voltage: 24VDC4.
Output voltage: 24VDC4.
Output points: 8 isolated points 4.
Operating temperature range: -40℃~ 85 ° C 4.
Product size: 40×40×30 (unit: not specified, may be mm) 4.
Product weight: 3.5 kg 4.
Output current range: 4~ 20mA4.
Resolution: 12 bits 4.
Output accuracy: less than 0.25%4.
Communication protocol: Ethernet /IP4.
Enclosure protection class: IP674.
