ABB HIEE401782R0001
The ABB HIEE401782R0001 module is an onboard functional module designed to meet the needs of industrial applications. It features a robust and vibration-resistant 314-pin MXM connector and can operate in an extended operating temperature range from -40°C to +85°C. The module is designed to increase efficiency by reducing interfaces and ensuring vertical smooth flow from the operational layer to the field layer. It also supports Profinet RT and IRT to speed up real-time data exchange, as well as open communication over TCP/IP. In addition, the module also allows for efficient development and future upgrade pat
hs with the next generation of SMARC COM1.
Product parameters:
Operating temperature range: -40°C to +85°C1
Connector type: 314-pin MXM connector 1
Communication support: Profinet RT and IRT, Profinet CBA, Profibus DP (optional) 2
Memory: 128 KB2
I/O device support: A maximum of 128 2
Protection level: IP202
Specifications:
Dimensions: May include detailed dimensions for width (W), height (H), and depth (D), but specific values are not provided in the search result2.
Interface: X1 is a PN interface module (3*RJ45), or Profibus DP master station interface module 2 is optional.
Other functions: Support SNMP, integrated web server functions, etc. 2.
