ABB EL3020 Electrical load monitoring

ABB EL3020

The ABB EL3020 module is an integral part of the ABB Ability™ electrical load monitoring solution for monitoring and analyzing the load conditions of electrical systems. The module has the following features:

ABB	EL3020 Electrical load monitoring

High precision: High precision current and voltage sensors are used to

ABB	EL3020 Electrical load monitoring1 achieve high precision load measurement.
Multi-function: Support a variety of measurement parameters, including current, voltage, power, harmonics, power factors, etc.
Easy to use: Modules are simple to configure and require no special tools.
Modular design: Supports flexible system expansion, and modules can be added or replaced as needed.
Reliable: Redundant design and advanced fault diagnosis function ensure the stable operation of the system.
Product parameters:

Parameter value unit
Measuring range Current: 0 to 3000 A, voltage: 0 to 690 V –
Measurement accuracy Current: ±0.5%, voltage: ±0.2% –
Sampling frequency 1 kHz –
Communication port Ethernet, RS485 –
Operating temperature -20 to 60 °C
Protection class IP20 –
Dimensions 116 mm x 230 mm x 176 mm –
Weight 3.0 kg
