ABB DSSR122
ABB DSSR122 is a digital servo driver for the control of direct current (DC) motors. It has the characteristics of high precision, high dynamic response and fast overload protection, and can be widely used in various industrial automation fields. The module supports a variety of control modes, including speed control, position control, torque control and pressure control.
Product parameters:
Exact parameter values cannot be provided due to the lack of detailed specifications. However, some general parameters that may be applicable to ABB DSSR122 modules include:
Rated voltage: 24V DC or 48V DC
Rated current: 10A to 20A
Peak current: 20A to 40A
Control accuracy: ±0.1%
Dynamic response: 2ms
Overload protection: 2 times rated current
Communication interface: RS232, RS485
Communication protocol: Modbus RTU
Operating temperature: -10°C to +50°C
Protection class: IP65
Specifications:
Dimensions: Approx. 115 mm x 175 mm x 45 mm
Weight: About 1.2kg
Material: Aluminum alloy
Additional information:
Certification: CE, FCC, UL (possible)
Warranty: 2 years (possible)
