ABB CI854AK01
ABB CI854AK01 is a PROFIBUS-DP/V1 communication interface module provided by ABB for its AC800M Distributed control System (DCS). It is mainly used to connect the AC800M system with the field equipment that supports PROFIBUS-DP/V1
protocol to realize data exchange and control. Through this module, various sensors, actuators, frequency converters and other equipment can be integrated into the AC800M system to build a complete automatic control system.
Main function
PROFIBUS-DP/V1 communication: Enables high-speed, reliable communication with devices that support the PROFIBUS-DP/V1 protocol.
Data transmission: Transfer digital, analog, status information between AC800M system and field equipment.
Redundant configuration: Supports redundant configuration to improve system reliability.
Product parameters (part)
The specific parameters may vary depending on the configuration. The following are the general parameters:
Communication protocol: PROFIBUS-DP/V1
Data transfer rate: 12 Mbit/s
Number of nodes: The value depends on the system configuration
Operating temperature: -20℃ ~ +60℃
Relative humidity: 5% ~ 95%
Product specification
Modular design: easy installation and maintenance.
High reliability: Suitable for industrial environment.
Flexible configuration: Flexible configuration based on system requirements.
Application field
Process industry: Automatic control system for petrochemical, electric power, metallurgy and other industries.
Infrastructure: water treatment, sewage treatment, etc.
Food and beverage: Control of food and beverage production process.
Matters needing attention
Installation: During installation, strictly follow the instructions to ensure that the cables are correctly connected.
Configuration: Configure modules based on system requirements.
Maintenance: Check the module regularly to make sure it is in good condition.
