ABB 5SHY5045L0020
The ABB 5SHY5045L0020 module is a key component in the ABB 5SHY series of High Voltage Direct current (HVDC) transmission systems for converting power from DC to AC or from AC to DC. The module has the following features:
High efficiency: The use of advanced semiconductor technology to achieve high efficiency power conversion.
High reliability: Redundant design and advanced fault diagnosis function ensure the stable operation of the system.
Compact design: Compact size, easy to install and maintain.
Environmental protection: The use of environmentally friendly materials, in line with the requirements of RoHS directive.
Product parameters:
Parameter value unit
Rated voltage 4500 V
Rated current 5000 A
Maximum shutdown current 6250 A
Switching loss 125 J
Conduction loss 62.5J
Operating temperature -40 to 55 °C
Cooling method Water cooling –
Weight 18 kg
