ABB 5SHY4045L0004
The ABB 5SHY4045L0004 module is an IGBT (insulated gate bipolar transistor) module manufactured by ABB for high voltage direct current (HVDC) transmission and conversion applications. It has the following characteristics:
High switching frequency: Higher efficiency and power density
Low loss: can reduce heat and power consumption
High reliability: can extend the service life
Long service life: reduces maintenance costs
Product parameters:
Parameter value
Model number 5SHY4045L0004
Series ACS 6000
Rated voltage 4500 V
Rated current 4000 A
Switching loss 3.0J
On-off loss 1.8V
Switching frequency 20 kHz
Junction temperature 175°C
