ABB 5SHY3545L0020
The full product name of the ABB 5SHY3545L0020 module is th
e ABB 5SHY Series 5SHY3545L0020 IGCT module.
Product Description:
The ABB 5SHY3545L0020 module is a key component in the ABB 5SHY series of High Voltage Direct current (HVDC) transmission systems for converting power from DC to AC or from AC to DC. The module has the following features:
High efficiency: The use of advanced semiconductor technology to achieve high efficiency power conversion.
High reliability: Redundant design and advanced fault diagnosis function ensure the stable operation of the system.
Compact design: Compact size, easy to install and maintain.
Environmental protection: The use of environmentally friendly materials, in line with the requirements of RoHS directive.
Product parameters:
Parameter value unit
Rated voltage 4500 V
The rated current is 3500 A
Maximum shutdown current 5250 A
Switch loss 100 J
Conduction loss 50 J
Operating temperature -40 to 55 °C
