ABB 5SHY3545L0014 3BHB013085R0001
The ABB 5SHY3545L0014 and 3BHB013085R0001 modules are an important part of ABB’s programmable Logic controller (PLC) system. They are often used together to provide reliable control and automation functions for a variety of industrial applications.
Product name
5SHY3545L0014: The full product name for this module is ABB AC800M I/O Module 32DI/32DO/8AI/4AO 5SHY3545L0014.
3BHB013085R0001: The full product name for this module is ABB AC800M Expansion Module 3BHB013085R0001.
Product description
The 5SHY3545L0014 module is a digital and analog I/O module for connecting field equipment to ABB AC800M PLC systems. It has the following characteristics:
32 digital input channels
32 digital output channels
8 analog input channels
4 analog output channels
Multiple signal types are supported, including switching signals, analog voltage and current signals
High accuracy and reliability
Easy to install and maintain
The 3BHB013085R0001 module is an expansion module that provides additional functionality to ABB AC800M PLC systems. It has the following characteristics:
Provide additional I/O points
Various communication protocols are supported, including PROFIBUS DP and MODBUS
Supports multiple functions such as high-speed counting and pulse width modulation (PWM)
Product parameter
Parameter 5SHY3545L0014 3BHB013085R0001
Module Type Digital and analog I/O module Expansion module
Digital input channel 32 –
Digital output channel 32 –
Analog input channel 8 –
Analog output channel 4 –
Supported signal types Switching signal, analog voltage, current signal –
Communication protocols – PROFIBUS DP, MODBUS
Other features – High speed counting, PWM
