ABB 5SHX1445H0001 3BHL000391P0101
ABB 5SHX1445H0001 3BHL000391P0101 is an IGCT module for current control in power converters, power transmission and power distribution systems. It uses advanced semiconductor technology and has the characteristics of high efficiency, high reliability and long life. The module can be used in a variety of HVDC applications such as:
Wind farm access
Photovoltaic power station access
Flexible DC network
Electric vehicle charging
Product parameters:
Parameter value unit
Rated voltage 4500 V
Rated current 2500 A
Rated power 11.25 MW
Switching frequency 2000 Hz
On/off loss of 2.5%
The switch loss is 1.5%
Operating temperature range -40 to +85 °C
Relative humidity 5% to 95% % (non-condensing)
Protection class IP67 –
