ABB TB850 3BSC950193R1
The ABB TB850 3BSC950193R1 is an analog expansion module specifically designed for industrial automation applications. It can be connected to ABB’s controllers to provide additional analog input and output channels for monitoring and controlling various process variables.
Product parameters:
Input channels: 8
Input signal range: -10 V to +10 V or 4 mA to 20 mA
Input accuracy: ±0.1% FS
Number of output channels: 4
Output signal range: 0 V to 10 V or 4 mA to 20 mA
Output accuracy: ±0.1% FS
Isolation voltage: 2500 V RMS
Communication interface: Ethernet, RS485
Operating temperature range: -20 °C to +60 °C
Storage temperature range: -40 °C to +80 °C
Dimensions: 100 mm x 100 mm x 50 mm
Weight: 0.5kg
Specifications:
Complies with IEC 61000-4-2 Electrostatic Discharge (ESD) standards
Meets IEC 61000-4-3 Electrical Fast transients (EFT) standards
Meets IEC 61000-4-4 Radiation disturbance (EMI) standards
Comply with IEC 61000-4-5 SURGE voltage standard
Compliance with IEC 61000-4-6 Conductive Interference (EMI) standards
