ABB REF615A_E HAFAABAAABE1BCA1XE
ABB REF615A_E HAFAABAAABE1BCA1XE module: Details
Product Name:
The ABB REF615A_E HAFAABAAABE1BCA1XE module, also known as the High voltage circuit Breaker control module, is an industrial control device for controlling high voltage circuit breakers. It is part of the ABB Relion family of products designed to protect and control high voltage switchgear.
Product Description:
The REF615A_E HAFAABAAABE1BCA1XE module has the following features:
Multiple protection functions: Provides overload protection, short circuit protection, overvoltage protection, undervoltage protection, ground fault protection, stall protection and other protection functions to ensure the safe operation of high voltage switchgear.
Precise control: It can accurately control the switching operation of the high-voltage circuit breaker to ensure the stable operation of the power grid.
Flexible communication: Multiple communication protocols such as Modbus RTU, Profibus DP and EtherNet/IP are supported for easy integration into SCADA systems.
Easy to use: provides a friendly interface and a variety of programming methods, easy to operate and configure.
High reliability: The use of high-quality components and circuit design, can ensure long-term stable operation.
The REF615A_E HAFAABAAABE1BCA1XE module can be used in a variety of high voltage switch applications, including:
Substation: Control substation main transformer, high voltage line and other equipment.
Power plant: control generators, boost transformers, transmission lines and other equipment.
Industrial power distribution systems: high-voltage power supply systems that control industrial buildings.
Railway traction system: control railway traction transformer, overhead contact line and other equipment.
Mine power distribution system: Control mine underground high voltage power supply system.
Product parameters:
Parameter value
Rated voltage 400 kV
Rated current 6300 A
Open capacity 63 kA
Operation time 0.2 seconds
Communication rate 9600 bps to 10 Mbps
Operating temperature range -25°C to +55°C
Storage temperature range -40°C to +70°C
Size 800 mm x 600 mm x 400 mm
