ABB PPD512
Description: ABB PPD512 module is a PROFIBUS DP slave module for ABB PROFIBUS DP fieldbus system. This module connects field devices to the PROFIBUS DP network for communication with the controller. The module has the following features:
Supports the PROFIBUS DP protocol
12 digital input channels
4 analog input channels
4 analog output channels
2 relay output channels
Operating temperature range: -25°C to +70°C
Meets IP67 protection rating
Product parameters:
Parameter value unit
Communication protocol PROFIBUS DP –
Number of input channels 12
The number of analog input channels is 4
The number of analog output channels is 4
Number of relay output channels 2
Operating temperature range -25°C to +70°C °C
Protection class IP67 –
Parameter value unit
Power terminal +24VDC, GND –
Digit input terminals DI0 to DI11 –
Analog input terminals AI0 to AI3 –
Analog output terminals AO0 to AO3 –
Relay output terminals Q0, Q1 –
PROFIBUS DP interface SUBD 9-pin –
