ABB 3ASC25H219B DATX133
The Chinese name of 3ASC25H219B DATX133 module is digital high voltage distribution system sensor pulse signal processing board 2. It is a module in the ABB AbilityTM System 800xA Safety Instrumentation System (SIS) to capture voltage and current signals from high-voltage distribution systems and convert them into information that can be recognized by the controller. It has high reliability and security and can be used in a variety of safety-critical applications.
Product description
The features of this module include:
Supports a variety of high pressure sensors、
High diagnostic coverage allows early detection of faults
Meets IEC 61508 SIL 2/3 safety level requirements
Product parameter
Parameter value
Module Type Digital high voltage distribution system sensor pulse signal processing board 2
Support sensor type Voltage sensor, current sensor
The input signal range can be configured as required
Accuracy ±0.1%
Resolution 16 bit
Response time ≤250 ms
Power supply voltage 24 VDC
Power consumption 2 W
Operating temperature range -40°C to +70°C
Storage temperature range -55°C to +85°C
Relative humidity 5% to 95% (non-condensing)
Vibration resistance 2 g (10 Hz to 500 Hz)
Impact resistance 10 g (11 ms)
Dimensions 146 mm x 110 mm x 40 mm
Weight 1 kg
