AB 1786-RG6
The 1786-RG6 is a four-shielded coaxial cable for the ControlNet network manufactured by Rockwell Automation. It is used to connect ControlNet devices, such as controllers, I/O modules, and sensors. The cable has the following features:
RG-6 Coaxial cable structure
Four-shield design provides excellent anti-interference performance
Good damping characteristics, can transmit long distance signals
Suitable for indoor and outdoor applications
Product parameters:
Cable type: RG-6 coaxial cable
Mask type: four mask
Characteristic impedance: 95 Ω
Attenuation: 5.99 dB/1000 ft (19.6 dB/km) @ 10 MHz
Maximum transmission distance: 6,000 ft (1,829 m)
Operating temperature: -40°C to 80°C (-40°F to 176°F)
Specifications:
Diameter: 7.5mm (0.30″)
Weight: Approximately 0.12 kg/m (0.08 lb/ft)
Bending radius: min. 38 mm (1.5″)
Rated voltage: 300V AC
