AB 1756-BA2
The AB 1756-BA2 module is a 3V lithium battery module used by ControlLogix controllers and CompactLogix controllers. It is used to provide backup power to the controller to keep programs and data running in the event of a primary power failure. It has the following characteristics:
The rated voltage is 3 volts
Capacity is 2.5 ampere-hours
The typical service life is 10 years
Supports hot swap
Product parameters:
Battery type: Lithium battery
Voltage: 3 volts
Capacity: 2.5 amps
Operating temperature: -40°C to 85°C (-40°F to 185°F)
Storage temperature: -40°C to 85°C (-40°F to 185°F)
Self-discharge rate: less than 5% per year
Specifications:
Dimensions: 65 mm x 30 mm x 10 mm (2.56 “x 1.18” x 0.39 “)
Weight: 30g (1.06 oz)
Applications:
The AB 1756-BA2 module can be used in the following applications:
Backup power for ControlLogix and CompactLogix controllers
Keep programs and data running in the event of a main power failure
Improve the reliability of the control system
