A-B 1756-TBNH
The AB 1756-TBNH module is an accessory to the Rockwell Automation (Allen-Bradley) ControlLogix series of controllers that is a removable terminal (RTB). It is mainly used to connect the ControlLogix I/O module, providing a convenient and quick connection method.
Main functions:
Wiring connection: Connect external wires to the ControlLogix I/O module.
Modular design: easy to install and disassemble, easy to maintain and replace.
Improve reliability: Provide stable electrical connections and reduce failure rates.
Product parameters and specifications (for some parameters, please refer to the produ
ct manual) :
Model: 1756-TBNH
Manufacturer: Rockwell Automation (Allen-Bradley)
Type: Terminal removable
Number of pins: 20
Installation mode: Directly install the ControlLogix I/O module
Operating temperature: 0℃ ~ 55℃
Features:
Easy installation: pluggable design, easy and quick installation.
High reliability: The use of high-quality materials to ensure reliable connection.
Modular design: Terminals can be added or reduced as needed.
Application field:
ControlLogix system: Mainly used to connect I/O modules in ControlLogix system.
Industrial automation: Widely used in various industrial automation systems, providing flexible wiring methods.
Note:
Compatibility: Ensure compatibility with your ControlLogix I/O module.
Wiring: During installation, strictly follow the product manual for wiring to avoid short circuit.
Maintenance: Periodically check the connection of wiring terminals.
