A-B 1756-OF8The A-B 1756-OF8 analog output module is an analog output module manufactured by Rockwell Automation. This module is designed to convert digital signals in digital control systems to analog signal output, which is commonly used in industrial automation, such as controlling motor speed, temperature regulation, etc. 1. It features eight independent analog output channels, each of which can be configured individually, with an output rating of
±10 volts or 0 to 20 mA, and a voltage or current output range of -10 to 10V or 4 to 20 mA23.
Product parameters:
Number of channels: 8 independent analog output channels 123
Output range: ±10 volts or 0 to 20 mA23
Signal resolution: The signal resolution is 15 bits at 21 mA and 15 bits 23 at 10.4 volts
Power consumption: The large power consumption of the circuit is 5.8 watts, and the total fixed power is also 5.8 watts 2
Backplane current: at 24 volts DC, the backplane current is 210 mA; At 5.1 volts, the backplane current is 150 mA DC volts 23
