A-B 1756-OF4
The A-B 1756-OF4 module is an analog output module designed by Rockwell Automation (Allen-Bradley) for its ControlLogix series PLC. It is mainly used to convert the digital signal inside the PLC into an analog signal, so as to control the external analog equipment, such as valves, motors, etc.
Main function
Analog output: The PLC’s digital signal is converted to 4-20mA or 0-10V analog signal.
High precision: provides high output accuracy to ensure the accuracy of control.
Multi-channel output: With 4 independent output channels, you can control multiple analog devices at the same time.
Flexible configuration: Supports multiple output ranges and unit configurations to meet different application requirements.
Diagnostic function: With self-diagnostic function, you can monitor the working status of the module.
Product parameters and specifications (typical values, refer to the product data manual)
Number of channels: 4
Output type: 4-20mA or 0-10V
Resolution: 12 bits
Sampling rate: Configurable
Power supply: From ControlLogix baseboard
Installation mode: Installed on the ControlLogix mainboard
Application field
Process control: used to control various process variables, such as temperature, pressure, flow, etc.
Motion control: Used to control the output of the servo drive to achieve accurate motion control.
Data acquisition: used to convert digital signals to analog signals,
