A-B 1756-IF16The Allen-Bradley 1756-IF16 is an analog input module in the ControlLogix family of controllers manufactured by Rockwell Automation. It is mainly used to collect analog signals from sensors, transmitters and other devices, and convert them into digital signals that can be recognized by PLC for subsequent control and processing.
Product parameters and specifications
Number of channels: 16 single-ended input channels that can be configured as 8 differential inputs or 4 differential inputs
Input range: ±10.25V, 0-10.25V, 0-5.125V, 0-20.5mA, etc
Resolution: 320 µV/count, 160 µV/count, 80 µV/count, 0.32 µA/count, etc
Sampling rate: High speed sampling
Mounting method: DIN rail mounting
Protection level: Depending on the specific application environment
peculiarity
High precision: provides high resolution analog input to ensure the accuracy of data.
Flexible configuration: Input range and channel mode can be configured according to different application requirements.
High-speed sampling: Meet the measurement requirements of high-speed dynamic processes.
High reliability: suitable for harsh industrial environments.
