A-B 1756-IF16The Allen-Bradley 1756-IF16 is an analog input module that belongs to the ControlLogix family. It is mainly used to convert analog signals (such as voltage and current) from sensors, transmitters and other devices into digital signals that PLC can process. These analog signals usually represent physical quantities, such as temperature, pressure, flow, etc. This module is widely used in process control, data acquisition and other fields.
Product parameters (part)
Model: 1756-IF16
Number of channels: 16
Input type: single-ended or differential
Measuring range: ±10V, 0-10V, 0-5V, 0-20 mA, etc. (configurable)
Resolution: High resolution to ensure measurement accuracy
Isolation: Each channel is isolated to improve system reliability
Communication interface: ControlLogix bus
Power Supply: Obtain it from the ControlLogix backplane
Mounting method: DIN rail mounting
specification
Dimensions: According to the specific configuration
Weight: depends on the specific configuration
Working environment: 0-60℃, relative humidity below 95% (no condensation)
Certification: UL, CSA, CE, etc
