A-B 1756-HSC
The Allen-Bradley 1756-HSC module is a modular input/output device designed for high precision counting and speed control. It is typically integrated on Rockwell Automation’s ControlLogix platform and is used in various industrial automation applications. The module can count the pulse signals of external devices with high speed and accuracy, and provides a variety of counting modes and control functions.
Product parameters and specifications (general) :
Model: 1756-HSC
Functions: high-speed counting, speed control, position control
Input type: Usually differential input to improve noise resistance
Counting frequency: Very high, depending on model and configuration
Count mode: Support a variety of count modes, such as up count, down count, two-way count, etc
Control function: Provide a variety of control functions, such as speed setting, position setting, limit protection, etc
Communication interface: Communicates with the ControlLogix platform’s DH+ or Ethernet/IP
Power supply: From ControlLogix baseboard
Ambient temperature: Suitable for industrial environment
Installation mode: Installed on the ControlLogix controller mainboard
Main applications:
Motion control: used for servo motor, stepper motor and other equipment speed and position control
High-speed counting: used to measure speed, flow, length, etc
Data acquisition: Used for high-speed data acquisition
